AeroPoint 300

Part No: 89000036-001

Shipping calculated at checkout.
Options: 4 Cylinder

AeroPoint 300

Introducing the AeroPoint 300 – a unique high-resolution single-display engine data management system available for twin-engine aircraft. The immediate feedback features of this system, along with the built-in learning procedure for leaning, offer detailed diagnostic information in a timely and useful format. From monitoring engine temperatures and voltages, adjusting the fuel / air mixture, to diagnosing engine malfunctions, the AeroPoint 300 will quickly become your favorite on-board flight engineer.

Operates in the background with continuous monitoring during the flight, without any pilot interaction. Warns when any parameter exceeds past the programmed limit. Displays engine data as well as logs maintenance data for a complete engine data management system.

Track flight data from the system directly to evaluate engine health, with an affordable price point. This single primary flight instrument replaces many of the old, outdated engine gauges, freeing up space and weight for other BendixKing upgrades.

Easy-to-mount system can be mounted in either landscape or portrait mode, and is configurable for all of your engine diagnostic and monitoring needs. The extensive standard feature list replaces many of your old engine gauges, and features only one DAU (data acquisition unit) per engine, so wiring remains concise and minimal.



    • Pre-wired harness for all functions
    • Pre-wired harnesses 8ft
    • RPM
    • VGA display
    • Manifold air pressure
    • Exhaust gas temperature
    • Cylinder head temperature
    • Outside air temperature (C or F)
    • Oil temperature replaces factory sender
    • Oil pressure
    • Fuel Flow, GPH, FloScan 201 or 231 transducer
    • Estimated fuel used
    • Estimated time to empty
    • Volts
    • Amp-1 with 100 amp Shunt
    • Percent horsepower
    • Data recording of all engine parameters with GPS position
    • USB memory stick 1 GB/ Recording
    • LOP and ROP algorithm
    • Trend charting software
    • 3 year warranty


    • Dimensions 4.73” H x 5.54” W x 2.4” D
    • Weight 24 Oz
    • Resolution 1°F
    • Linearized accuracy 1 degree
    • Display 1000 nits
    • Voltage 7.5 to 35 volts at ½ amp
