AEROLEDS

SunSpot 36-4000 Series 75W Collection - Landing

Part No: 01-1030-4509-H

$449.00
Shipping calculated at checkout.
Voltage: 12v
DESCRIPTION

SunSpot 36-4000 Series 75W Collection - Landing

The SunSpot 36-4000 Series 75W tops the charts with the HIGHEST
CANDELA IN THE INDUSTRY for a PAR 36 LED landing light. At just
75W, this line boasts an outstanding 200,000+ candela with a 15°x15°
bright white beam angle that greatly improves visibility both on
the ground and in the air from up to 30 miles away.

-H MODEL includes AeroLEDs signature integrated Pulse (WigWag)
functionality. This feature helps to significantly increase recognition in
both broad daylight as well as night operations, aiding in the avoidance
of midair collisions and bird strikes. While in operation, this self contained
pulse function reduces load on the electrical system by 50% as compared
to incandescent bulbs.

The SunSpot 36 replacement LED’s utilize the existing PAR36 mount
and electrical connections for ease of installation. (-H versions require
an additional wire*)

Features

•Highest candela in the industry

• Power consumption: 75 watts
• Color temperature: aviation white
• Built-in pulse mode (-H models)
• Synchronization
• Easy installation
• 30k hr MTBF
• Built-in thermal protection
• Aluminum/black powder coated
heat sink
• UV hardcoated polycarbonate lens



Specifications



36-4000 SERIES 01-1030-4509 01-1030-4509-H 01-1030-4591 01-1030-4591-H
Certification FAA-PMA/STC
Nominal 14VDC 28V AC/DC
Voltage Minimum 9VDC 18V AC/DC
Maximum 15VDC 30V AC/DC
Current 5.4A @ 14VDC 2.7A @ 28VDC
Power 75W
Lumens 6,500
Candela 200,000
Beam Profile
(@10% peak) 15° Vertical x 15° Horizontal
Dimensions
(L x W x D) 4.4” x 4.4” x 2.0”
Weight 11.2oz
Mounting PAR36
