DYNON AVIONICS

SV-XPNDR-262

Part No: 101410-000

$1,750.00
Shipping calculated at checkout.
Options: SV-XPNDR-262
DESCRIPTION

The SV-XPNDR-262 Mode S transponder module is made for the SkyView System, with control and annunciation appearing on the SkyView Display. The transponder features TIS Traffic (USA only) and comes with a quick release mounting system that can be installed anywhere in the airplane that is convenient. At only 1 pound and 5.6" by 1.8" by 2.4", the transponder module can fit into the tiniest places. The SV-XPNDR-262 has a nominal output of 130W and it meets USA and Europe ADS-B Out mandates: Note, full ADS-B Out compliance requires a TSO-C146A GPS (WAAS) to be connected. Includes 3-year Dynon Warranty.

Features

For <15,000 feet, <175 knots

Integrated: Made for the SkyView System with control and annuciation appearing on the SkyView Display. The transponder module can be mounted anywhere in the airplane that is convenient.

Traffic: Features TIS Traffic (USA).

Small and Light with Easy Installation: At only 1 pound and 5.6” by 1.8” by 2.4”, the transponder module can fit into the tiniest places and aircraft. A quick release mounting system allows for simple installation and easy removal if needed for service.

Specifications
  • Weight: 0.9 Lb. (400 g)
  • Dimensions: 2.4” x 1.8” x 5.6” (62 x 45 x 141 mm)
  • Operating Temperature -40?F to +158?F (-40?C to + 70?C)
  • Cooling Requirement No fan required
  • Supply Voltage (DC): 9 - 33 V
  • Power Consumption: 5 Watts (typical) [idle: 0.15 A, active: 0.28 A at 14 V]
  • Certification: ETSO C88a, 2C112b, C166 and TSO C88b, C112c, C166a, approved for IFR and VFR flight
  • Compliance: ED-73B, ED-14F/DO-160F, DO-1778B, DO-254 level C, DO260A class BO, DO-181C
